Vane pump | Theoretical displacement Vi | Maximum speed | Highest pressure | |||||
HF-0, HF-1 HF-2 | HF-4, HF-5 | HF-0, HF-2 | HF-1, HF-4, HF-5 | |||||
series | Pump core specification | Intermittent | continuous | Intermittent | continuous | |||
Cc/rev | Rpm | Rpm | Bar | Bar | Bar | Bar | ||
T7B T7BS | E03 | 9.8 |
3600 |
1800 |
320* |
290 |
240 |
210 |
E04 | 12.8 | |||||||
E06 | 15.9 | |||||||
E07 | 22.5 | |||||||
E08 | 24.9 | |||||||
E09 | 28 | |||||||
E10 | 31.8 | |||||||
E11 | 35 |
300 |
275 | |||||
E12 | 41 |
3000 | ||||||
E14 | 45 | |||||||
E15 | 50 | 2700 | 280 | 240 | ||||
T7D T7DS | E14 | 44 |
3000 |
1800 |
300 |
250 |
240 |
210 |
E17 | 55 | |||||||
E20 | 66 | |||||||
E22 | 70.3 | |||||||
E24 | 81.1 | |||||||
E28 | 90 | |||||||
E31 | 99.2 | |||||||
E35 | 113.4 |
280 | ||||||
E38 | 120.6 | |||||||
E24 | 137.5 | |||||||
E24 | 137.5 | 2700 | 260 | 230 | ||||
*If the pressure exceeds 300bar, please contact Knowhow, the product size chart is also described
HF-0, HF-2 petroleum-based anti-wear hydraulic oil HF-1 petroleum-based hydraulic oil (non-anti-wear)
HF-4 water glycol HF-5 synthetic hydraulic oil (phosphoric acid solution, etc.)
& T7BB \ T7BBS \T7DB \T7DBS \ T7DD \T7DDS double series displacement combination available for selection
